POST /workflow/runs

Use the POST /workflow/runs endpoint to start a workflow.

Available HTTP methods

POST /workflow/runs

Prerequisites

  1. Add an API key.

  2. Generate an access token.

Base URL

All requests made to the POST /workflow/runs endpoint should be directed to the following base URL:

https://{tenant-id}.amperity.com/api/workflow/runs

Rate limit

A rate limit is the number of requests that may be made to the Amperity API in a given time period.

The Amperity API supports requests to endpoints that do not exceed a rate of 10 requests per second. Response times will vary by endpoint and the complexity of data that is returned by the response. Some requests may take seconds to return.

Requests to the Amperity API that exceed 10 requests per second may return an error response with an HTTP 429 status code.

Requests

A request to the POST /workflow/runs endpoint is similar to:

curl --request POST \
       'https://app.amperity.com/api/workflow/runs' \
     --header 'amperity-tenant: tenant' \
     --header 'api-version: 2024-04-01' \
     --header 'Authorization: Bearer token' \
     --data '{"config_id"="cg-123ABc4DE"}'

(This example is formatted for readability in a narrow page layout.)

Request parameters

The following table describes the parameters that may be used with the POST /workflow/runs endpoint.

Parameter

Description

api_version

String. Optional.

A supported version of the Amperity API. For example: 2024-04-01.

Note

You may use the api-version request header instead of the api_version request parameter.

config_id

String. Required.

The configuration ID of the workflow. This may be the ID for a courier group, orchestration group, or campaign.

You can find the ID for the workflow to be run in the following locations:

  • From the Sources page, open the menu in the same row as the courier group, and then select Copy ID.

  • From the Destinations page, open the menu in the same row as the orchestration group, and then select Copy ID.

  • From the Campaigns page, open the menu in the same row as the campaign, and then select Copy ID.

range_from

String. Required for file-based workflows. Courier groups only.

Important

A value for range_from must be specified for any courier group that is configured to pull files from cloud storage (SFTP, Amazon S3, Azure Blob Storage, or Google Cloud Storage).

A timestamp that defines the start (inclusive) of the time window for which couriers in the workflow should pull data. See the range_to request parameter.

A timestamp must be in ISO 8601 format and in Coordinated Universal Time (UTC).

Tip

Use with range_to to define a date range within which to look for files. This date range will be inclusive of range_from and exclusive of range_to.

Use without range_to to define a specific day on which to run the workflow.

range_to

String. Optional. Courier groups only.

Important

A value for range_from must be specified when range_to is included in the request.

A timestamp that defines the end (exclusive) of the time window for which couriers in the workflow should pull data. See the range_from request parameter.

A timestamp must be in ISO 8601 format and in Coordinated Universal Time (UTC).

run_mode

String. Optional. Courier groups only.

Indicates the run mode for the courier group workflow. Possible values: full, refresh, or source.

  • Use full to pull data, refresh domain tables, run Stitch, update databases, then send workflow results downstream. All activations, including orchestrations, campaigns, and journeys, that are associated with this workflow will be run.

  • Use refresh to pull data, refresh domain tables, run Stitch, and then update databases.

  • Use source to pull data and refresh domain tables.

Tip

run_mode will default to the run mode that is configured for the scheduled workflow. You may override the configured setting by providing a value for run_mode in the request.

Request examples

The following examples show how to send requests to the POST /workflow/runs endpoint.

cURL, run campaign

The following example shows how to use cURL to send a request to the POST /workflow/runs endpoint to run a campaign.

curl --request POST \
       'https://app.amperity.com/api/workflow/runs' \
     --header 'amperity-tenant: tenant' \
     --header 'api-version: 2024-04-01' \
     --header 'Authorization: Bearer token' \
     --data '{"config_id"="cc-123ABc4DE"}'

(This example is formatted for readability in a narrow page layout.)

cURL, run courier group

The following example shows how to use cURL to send a request to the POST /workflow/runs endpoint to run a courier group.

curl --request POST \
       'https://app.amperity.com/api/workflow/runs' \
     --header 'amperity-tenant: tenant' \
     --header 'api-version: 2024-04-01' \
     --header 'Authorization: Bearer token' \
     --data '{"config_id"="cg-123ABc4DE"}' \
     --data '{"range_from"="YYYY-MM-DD"}' \
     --data '{"range_to"="YYYY-MM-DD"}' \
     --data '{"run_mode"="full"}'

(This example is formatted for readability in a narrow page layout.)

cURL, run orchestration

The following example shows how to use cURL to send a request to the POST /workflow/runs endpoint to run an orchestration.

curl --request POST \
       'https://app.amperity.com/api/workflow/runs' \
     --header 'amperity-tenant: tenant' \
     --header 'api-version: 2024-04-01' \
     --header 'Authorization: Bearer token' \
     --data '{"config_id"="og-123ABc4DE"}'

(This example is formatted for readability in a narrow page layout.)

Python

The following example shows how to use Python to send a request to the POST /workflow/runs endpoint.

import requests

# Your API endpoint
url = "https://app.amperity.com/api/workflow/runs"

bearer_token = dbutils.secrets.get(scope = "tenant-bridge-api-access", key = "tenant-bridge-api-access")

# Headers including authorization and custom headers
headers = {
  "Authorization": f"Bearer {bearer_token}",
  "amperity-tenant": "bridge",
  "api-version": "2024-04-01"
}

# Body of the request
body = {
  "config_id": "cg-2efo5X8vo",
  "range_from": "YYYY-MM-DD",
  "range_to": "YYYY-MM-DD",
  "run_mode": "source"
}

# Make the POST request
response = requests.post(url, headers=headers, json=body)

# Print the response
print("Status Code:", response.status_code)
print("Response Body:", response.text)

Responses

A response from the POST /workflow/runs endpoint will match an HTTP status code. A 200 response will contain workflow details for the workflow run that was started. A 4xx response indicates an issue with the configuration of your request. A 5xx response indicates that the endpoint is unavailable.

200 OK

The 200 response returns details for the workflow that was started, similar to:

{
  "task_instances":[],
  "id":"wf-123456A-78901-2bcd3e",
  "name":"Daily",
  "principal_name":"Daniel Kuhlman",
  "principal_id":"abc-EFghIjKL1Mn",
  "type":"courier.group/run",
  "launched_version":"abc-123456A-78901-2bcd3",
  "state":"scheduled",
  "created_at":"2025-04-18T15:33:51.724Z",
  "tenant":"bridge",
  "current_version":"abc-123456A-78901-2bcd3"
}

Response parameters

A 200 OK response contains the following parameters.

Parameter

Description

created_at

The date and time at which the workflow started.

current_version

A unique identifier that describes the configuration state of Amperity at the start of the workflow. The value for this property is similar to: “etv-20240210-12345-6AbCDE”.

id

The Amperity internal identifier for the workflow. For example wf-20240619-14418-6UhqSe.

launched_version

A unique identifier that describes the configuration state of Amperity at the start of the workflow. The value for this property is similar to: “etv-20240210-12345-6AbCDE”.

name

The name of the workflow.

Note

This is the same value that is visible from the title of each individual workflow page and from the Name column on the Workflows page.

principal_id

A unique identifier for the Amperity user who started the workflow. For example: “google-apps|socktown@socktown.com”.

principal_name

The name of the Amperity user who started the workflow. For example: “Daniel Kuhlman” or “Automated workflow”.

state

The state of the workflow.

task_instances

A JSON array that contains zero (or more) sets of the following parameters, one set for each task in the workflow. The list of parameters returned in the response may vary, depending on the type of task.

started_at

The date and time at which a workflow task started.

Note

This is the same value as the Completed field in the Task Details dialog, which can be opened from the actions menu (  ) for each task in the workflow.

execution_type

The service that runs a workflow task. Possible return values are spark-sql, prodigal, prodigal-aurora, databricks, identity, task-identity, legacy.

id

The unique identifier for the task instance.

Note

This is the same value as the Task ID field in the Task Details dialog, which can be opened from the actions menu (  ) for each task in the workflow.

label

The name of the task instance. Examples of task instance labels include:

  • Appending outputs of treatment [treatment] into campaign recipients table

  • Deleting records

  • Generating database

  • Getting query results

  • Getting segment results

  • Migrating [schema] schema

  • Recording segment tracking history

  • Resolving input tasks

  • Runing query: [query]

  • Running segment

  • Syncing tables

  • Truncating tables

  • Validating database [database-name]

  • Updating domain tables

  • Updating [table-name]

where the brackets [] are placeholders for named objects withn your tenant.

Note

This is the same value that is visible from the Task column on each individual workflow page.

run_id

A unique identifier provided to the task instance to support situations where execution engines cannot provide a run ID. The value for this property is similar to: “abc-20240210-12345-6AbCDE”.

Note

This is the same value as the Job ID field in the Task Details dialog, which can be opened from the actions menu (  ) for each task in the workflow.

state

The current state of the task. For example:

  • Scheduled

  • Started

  • In progress

  • Running

  • Finalizing

  • Succeeded

  • Stopping

  • Stopped

  • Failed

  • Skipped

  • Canceled

Note

This is the same value that is visible from the Status column on each individual workflow page. Some values are only visible while a task is active.

task_definition_id

A unique identifier for a task definition.

These values often contain human-readable strings within a series of alphanumeric characters. For example, a task that runs a SQL query that updates the view for the Unified Scores table has a task definition ID similar to ab-create-view-db-1a2BcdEFGhI-unified_scores.

task_definition_type

The task definition type. The possible values for this property are the similar to the type property for the workflow. For example, “bridge.sync” or “campaign.append-results”.

Note

This is the same value as the Definition ID field in the Task Details dialog, which can be opened from the actions menu (  ) for each task in the workflow.

tenant

The unique identifier for the tenant.

timeout_ms

The length of time (in milliseconds) after which a running task instance will be forced to stop.

workflow_id

The unique identifier for the workflow to which this task belongs.

tenant

The unique identifier for the tenant.

type

The type of workflow. Most workflows will have workflow types related to the following areas within Amperity:

  • Bridge sync

  • C360 validation

  • Campaign results

  • Campaign send

  • CCPA delete

  • Compact campaign recipients table

  • Courier

  • Courier group

  • Data refresh

  • Database

  • Domain table schema migration

  • File upload

  • Ingest

  • Input validation report update

  • Manual campaign run

  • Manual index run

  • Orchestration

  • Orchestration group

  • Predictive job

  • Record deletion

  • System migration on campaigns recipients table

  • UID2 enrichment

  • Update campaign recipients table

Note

This is the same value that is visible from the Type box on each individual workflow page and from the Type column on the Workflows page.
