Pull orders data from Toast¶
Toast is a collection of cloud-based restaurant products and tools that integrates restaurant operations with the Toast point-of-sale app and Toast hardware to process orders and payments at restaurant locations.
The Toast Orders API has information on orders, including checks, items ordered, prices, payment methods, discounts, and customer data.
Configuration options¶
Amperity does not integrate directly with the Toast Orders API. Orders data must be collected as an intermediate step, after which it can be sent to Amperity. Options include:
Building an AWS Lambda workflow. Use an Amazon AWS Lambda function to access the Toast Orders API and collect order data for the past seven days, serialize order data to Amazon S3 storage as a gzipped JSON file, and then send order data on a weekly schedule to the Amperity Streaming API.
The option to use an example AWS Lambda workflow requires custom AWS Lambda code that must be validated by your brand. The specific steps your brand requires may be different.
Access to the Toast Orders API and access to an Amperity streaming endpoint is required. Use this approach when your brand wants direct control over how data is accessed and where that data is stored.
Using Fivetran to access to the Toast Orders API, and then configure Amperity to pull orders data from Toast using Fivetran. Use this option when Fivetran can be given permission to access your brand’s Toast account.
Configure Amazon AWS¶
Configure Amazon AWS for a AWS Lambda function, Amazon S3 storage, and logging.
![]() |
Prerequisites To access the Toast Orders API you will need the following:
To configure your Amazon AWS account you will need permission to:
To access the Amperity Streaming API:
|
||||||||||||||||
![]() |
Create an Amazon S3 bucket
|
||||||||||||||||
![]() |
Create an IAM role for AWS Lambda
|
||||||||||||||||
![]() |
Create an AWS Lambda function
|
||||||||||||||||
![]() |
Deploy the code for the AWS Lambda function
|
||||||||||||||||
![]() |
Install dependencies The function uses external libraries. Add an AWS Lambda layer or package the dependencies. AWS Lambda Layer
Deployment Package
|
||||||||||||||||
![]() |
Configure environment variables
|
||||||||||||||||
![]() |
Configure function settings
|
||||||||||||||||
![]() |
Create schedule
|
||||||||||||||||
![]() |
Validate the function
|
Example Lambda function: toast-orders.py¶
The following example is a Lambda function that:
Authenticates to the Toast API and uses the correct headers.
Automatically calculates the previous week’s date range.
Fetches orders data, using pagination for large results.
Serializes orders data into JSON, and then compresses the results using gzip.
Includes metadata, such as export timestamps, data ranges, and order counts.
Applies error handling and retry logic.
Example Lambda function
import json
import boto3
import gzip
import os
import requests
from datetime import datetime, timedelta
from typing import Dict, Any, Optional
import logging
# Configure logging
logger = logging.getLogger()
logger.setLevel(logging.INFO)
class ToastOrdersProcessor:
def __init__(self):
# Toast API configuration - Set these as environment variables
self.toast_api_url = os.environ.get('TOAST_API_URL') # e.g., "https://ws-api.toasttab.com/orders/v2/orders"
self.toast_client_id = os.environ.get('TOAST_CLIENT_ID') # Your Toast client ID
self.toast_client_secret = os.environ.get('TOAST_CLIENT_SECRET') # Your Toast client secret
self.toast_restaurant_guid = os.environ.get('TOAST_RESTAURANT_GUID') # Your restaurant GUID
# AWS S3 configuration - Set these as environment variables
self.s3_bucket = os.environ.get('S3_BUCKET_NAME') # e.g., "my-toast-orders-bucket"
self.s3_prefix = os.environ.get('S3_PREFIX', 'toast-orders/') # Optional prefix for S3 objects
# Amperity configuration - Set these as environment variables
self.amperity_api_url = os.environ.get('AMPERITY_API_URL') # e.g., "https://socktown.amperity.com/api/v1/streaming"
self.amperity_api_key = os.environ.get('AMPERITY_API_KEY') # Your Amperity API key
self.amperity_tenant_id = "socktown" # Fixed tenant ID as specified
# Initialize AWS clients
self.s3_client = boto3.client('s3')
def get_toast_access_token(self) -> Optional[str]:
"""
Authenticate with Toast API using client credentials flow.
Returns access token or None if authentication fails.
"""
try:
auth_url = "https://ws-api.toasttab.com/authentication/v1/authentication/login"
payload = {
"clientId": self.toast_client_id,
"clientSecret": self.toast_client_secret,
"userAccessType": "TOAST_MACHINE_CLIENT"
}
headers = {
"Content-Type": "application/json",
"Toast-Restaurant-External-ID": self.toast_restaurant_guid
}
response = requests.post(auth_url, json=payload, headers=headers, timeout=30)
response.raise_for_status()
auth_data = response.json()
return auth_data.get('sessionToken')
except Exception as e:
logger.error(f"Failed to authenticate with Toast API: {str(e)}")
return None
def fetch_toast_orders(self, access_token: str) -> Optional[Dict[str, Any]]:
"""
Fetch orders from Toast API for the past week.
Returns orders data or None if fetch fails.
"""
try:
# Calculate date range for the past week
end_date = datetime.utcnow()
start_date = end_date - timedelta(days=7)
# Format dates for Toast API (ISO 8601 format)
start_date_str = start_date.strftime("%Y-%m-%dT%H:%M:%S.%fZ")
end_date_str = end_date.strftime("%Y-%m-%dT%H:%M:%S.%fZ")
headers = {
"Authorization": f"Bearer {access_token}",
"Content-Type": "application/json",
"Toast-Restaurant-External-ID": self.toast_restaurant_guid
}
# Toast API parameters for fetching orders
params = {
"startDate": start_date_str,
"endDate": end_date_str,
"pageSize": 100 # Adjust based on your needs, max is typically 100
}
all_orders = []
page_token = None
# Handle pagination
while True:
if page_token:
params["pageToken"] = page_token
response = requests.get(
self.toast_api_url,
headers=headers,
params=params,
timeout=60
)
response.raise_for_status()
data = response.json()
orders = data.get('orders', [])
all_orders.extend(orders)
# Check for next page
page_token = data.get('nextPageToken')
if not page_token:
break
logger.info(f"Fetched {len(orders)} orders, continuing to next page...")
logger.info(f"Successfully fetched {len(all_orders)} total orders from Toast API")
return {
"orders": all_orders,
"metadata": {
"fetch_date": end_date.isoformat(),
"start_date": start_date_str,
"end_date": end_date_str,
"total_orders": len(all_orders)
}
}
except Exception as e:
logger.error(f"Failed to fetch orders from Toast API: {str(e)}")
return None
def upload_to_s3(self, data: Dict[str, Any]) -> Optional[str]:
"""
Upload gzipped JSON data to S3 bucket.
Returns S3 key if successful, None otherwise.
"""
try:
# Generate filename with datestamp
timestamp = datetime.utcnow().strftime("%Y%m%d_%H%M%S")
filename = f"toast-orders_{timestamp}.json.gz"
s3_key = f"{self.s3_prefix}{filename}"
# Convert data to JSON and compress with gzip
json_data = json.dumps(data, indent=2)
compressed_data = gzip.compress(json_data.encode('utf-8'))
# Upload to S3
self.s3_client.put_object(
Bucket=self.s3_bucket,
Key=s3_key,
Body=compressed_data,
ContentType='application/json',
ContentEncoding='gzip',
Metadata={
'source': 'toast-orders-lambda',
'timestamp': timestamp,
'total_orders': str(data.get('metadata', {}).get('total_orders', 0))
}
)
logger.info(f"Successfully uploaded {filename} to S3 bucket {self.s3_bucket}")
return s3_key
except Exception as e:
logger.error(f"Failed to upload to S3: {str(e)}")
return None
def send_to_amperity(self, s3_key: str, data: Dict[str, Any]) -> Dict[str, Any]:
"""
Send data to Amperity Streaming API.
Returns response with status code and message.
"""
try:
headers = {
"Authorization": f"Bearer {self.amperity_api_key}",
"Content-Type": "application/json",
"Amperity-Tenant": self.amperity_tenant_id
}
# Prepare payload for Amperity
# Note: Adjust this payload structure based on Amperity's exact requirements
amperity_payload = {
"source": "toast-orders",
"data_type": "orders",
"s3_location": f"s3://{self.s3_bucket}/{s3_key}",
"metadata": {
"total_records": data.get('metadata', {}).get('total_orders', 0),
"fetch_date": data.get('metadata', {}).get('fetch_date'),
"start_date": data.get('metadata', {}).get('start_date'),
"end_date": data.get('metadata', {}).get('end_date')
},
"tenant_id": self.amperity_tenant_id
}
response = requests.post(
self.amperity_api_url,
headers=headers,
json=amperity_payload,
timeout=60
)
if response.status_code == 200:
logger.info("Successfully sent data to Amperity")
return {
"statusCode": 200,
"message": "Data successfully sent to Amperity",
"amperity_response": response.json() if response.text else {}
}
elif response.status_code == 400:
logger.error(f"Amperity validation error: {response.text}")
return {
"statusCode": 400,
"message": f"Amperity validation failed: {response.text}",
"error_details": response.text
}
else:
logger.error(f"Amperity API error: {response.status_code} - {response.text}")
return {
"statusCode": 500,
"message": f"Amperity API error: HTTP {response.status_code}",
"error_details": response.text
}
except requests.exceptions.Timeout:
logger.error("Timeout while sending data to Amperity")
return {
"statusCode": 500,
"message": "Timeout while sending data to Amperity"
}
except requests.exceptions.RequestException as e:
logger.error(f"Network error while sending to Amperity: {str(e)}")
return {
"statusCode": 500,
"message": f"Network error: {str(e)}"
}
except Exception as e:
logger.error(f"Unexpected error while sending to Amperity: {str(e)}")
return {
"statusCode": 500,
"message": f"Unexpected error: {str(e)}"
}
def lambda_handler(event, context):
"""
Main Lambda function handler.
This function will be triggered weekly on Monday at 4:00 AM UTC.
"""
processor = ToastOrdersProcessor()
try:
# Validate required environment variables
required_vars = [
'TOAST_API_URL', 'TOAST_CLIENT_ID', 'TOAST_CLIENT_SECRET',
'TOAST_RESTAURANT_GUID', 'S3_BUCKET_NAME', 'AMPERITY_API_URL',
'AMPERITY_API_KEY'
]
missing_vars = [var for var in required_vars if not os.environ.get(var)]
if missing_vars:
error_msg = f"Missing required environment variables: {', '.join(missing_vars)}"
logger.error(error_msg)
return {
"statusCode": 500,
"body": json.dumps({
"error": error_msg,
"missing_variables": missing_vars
})
}
# Step 1: Authenticate with Toast API
logger.info("Starting Toast Orders processing...")
access_token = processor.get_toast_access_token()
if not access_token:
return {
"statusCode": 500,
"body": json.dumps({
"error": "Failed to authenticate with Toast API"
})
}
# Step 2: Fetch orders from Toast API
orders_data = processor.fetch_toast_orders(access_token)
if not orders_data:
return {
"statusCode": 500,
"body": json.dumps({
"error": "Failed to fetch orders from Toast API"
})
}
# Step 3: Upload to S3
s3_key = processor.upload_to_s3(orders_data)
if not s3_key:
return {
"statusCode": 500,
"body": json.dumps({
"error": "Failed to upload data to S3"
})
}
# Step 4: Send to Amperity
amperity_result = processor.send_to_amperity(s3_key, orders_data)
# Return final result
return {
"statusCode": amperity_result["statusCode"],
"body": json.dumps({
"message": "Toast Orders processing completed",
"s3_location": f"s3://{processor.s3_bucket}/{s3_key}",
"total_orders": orders_data.get('metadata', {}).get('total_orders', 0),
"amperity_status": amperity_result["message"],
"timestamp": datetime.utcnow().isoformat()
})
}
except Exception as e:
logger.error(f"Unexpected error in lambda_handler: {str(e)}")
return {
"statusCode": 500,
"body": json.dumps({
"error": f"Unexpected error: {str(e)}",
"timestamp": datetime.utcnow().isoformat()
})
}
Example JSON payload¶
{
"orders": [
{
"guid": "a1b2c3d4-e5f6-7890-abcd-ef1234567890",
"entityType": "Order",
"externalId": null,
"orderNumber": "12345",
"openedDate": "2025-09-19T14:30:00.000Z",
"closedDate": "2025-09-19T14:45:00.000Z",
"modifiedDate": "2025-09-19T14:45:00.000Z",
"businessDate": 20250919,
"promisedDate": "2025-09-19T14:45:00.000Z",
"channelGuid": "b2c3d4e5-f6g7-8901-bcde-f23456789012",
"source": "ONLINE",
"duration": 900,
"dining": {
"guid": "c3d4e5f6-g7h8-9012-cdef-345678901234",
"entityType": "DiningOption",
"behavior": "DELIVERY",
"curbsidePickupInfo": null
},
"restaurant": {
"guid": "d4e5f6g7-h8i9-0123-def4-56789012345a",
"entityType": "Restaurant",
"locationName": "Main Street Location",
"locationId": "MAIN_001"
},
"revenueCenter": {
"guid": "e5f6g7h8-i9j0-1234-efg5-6789012345ab",
"entityType": "RevenueCenter",
"name": "Online Orders"
},
"server": {
"guid": "f6g7h8i9-j0k1-2345-fgh6-789012345abc",
"entityType": "Employee",
"firstName": "System",
"lastName": "Online",
"email": "system@restaurant.com"
},
"checks": [
{
"guid": "g7h8i9j0-k1l2-3456-ghi7-89012345abcd",
"entityType": "Check",
"displayNumber": "1",
"selections": [
{
"guid": "h8i9j0k1-l2m3-4567-hij8-9012345abcde",
"entityType": "Selection",
"item": {
"guid": "i9j0k1l2-m3n4-5678-ijk9-012345abcdef",
"entityType": "MenuItem",
"name": "Margherita Pizza",
"plu": "PIZZA001"
},
"itemGroup": {
"guid": "j0k1l2m3-n4o5-6789-jkl0-12345abcdef0",
"entityType": "MenuGroup",
"name": "Pizzas"
},
"quantity": 1,
"unitOfMeasure": "NONE",
"selectionType": "NONE",
"deferred": false,
"preDiscountPrice": 1599,
"price": 1599,
"tax": 144,
"voided": false,
"voidDate": null,
"voidBusinessDate": null,
"modifiers": [
{
"guid": "k1l2m3n4-o5p6-789a-klm1-2345abcdef01",
"entityType": "Selection",
"item": {
"guid": "l2m3n4o5-p6q7-89ab-lmn2-345abcdef012",
"entityType": "MenuItem",
"name": "Extra Cheese",
"plu": "MOD001"
},
"quantity": 1,
"unitOfMeasure": "NONE",
"selectionType": "NONE",
"preDiscountPrice": 200,
"price": 200,
"tax": 18
}
]
},
{
"guid": "m3n4o5p6-q7r8-9abc-mno3-45abcdef0123",
"entityType": "Selection",
"item": {
"guid": "n4o5p6q7-r8s9-abcd-nop4-5abcdef01234",
"entityType": "MenuItem",
"name": "Caesar Salad",
"plu": "SALAD001"
},
"itemGroup": {
"guid": "o5p6q7r8-s9t0-bcde-opq5-abcdef012345",
"entityType": "MenuGroup",
"name": "Salads"
},
"quantity": 1,
"unitOfMeasure": "NONE",
"selectionType": "NONE",
"deferred": false,
"preDiscountPrice": 899,
"price": 899,
"tax": 81,
"voided": false,
"voidDate": null,
"voidBusinessDate": null,
"modifiers": []
}
],
"customer": {
"guid": "p6q7r8s9-t0u1-cdef-pqr6-bcdef0123456",
"entityType": "Customer",
"firstName": "John",
"lastName": "Smith",
"email": "john.smith@email.com",
"phone": "+1-555-123-4567"
},
"payments": [
{
"guid": "q7r8s9t0-u1v2-def0-qrs7-cdef01234567",
"entityType": "Payment",
"paidDate": "2025-09-19T14:42:00.000Z",
"paidBusinessDate": 20250919,
"type": "CREDIT",
"amount": 2961,
"tipAmount": 300,
"amountTendered": 2961,
"cardEntryMode": "KEYED",
"last4Digits": "1234",
"cardType": "VISA"
}
],
"appliedDiscounts": [],
"taxAmount": 243,
"totalAmount": 2961,
"paymentStatus": "PAID"
}
],
"appliedDiscounts": [],
"discountAmount": 0,
"netAmount": 2698,
"taxAmount": 243,
"totalAmount": 2961,
"paidDate": "2025-09-19T14:42:00.000Z",
"closed": true,
"voidDate": null,
"voidBusinessDate": null,
"voided": false,
"approvalStatus": "APPROVED",
"deliveryInfo": {
"address": {
"address1": "123 Main Street",
"address2": "Apt 4B",
"city": "Anytown",
"state": "CA",
"zipCode": "12345",
"country": "US",
"latitude": 37.7749,
"longitude": -122.4194
},
"deliveryDate": "2025-09-19T15:15:00.000Z",
"deliveryCharge": 0,
"deliveryInstructions": "Ring doorbell twice"
}
},
{
"guid": "r8s9t0u1-v2w3-ef01-rst8-def012345678",
"entityType": "Order",
"externalId": null,
"orderNumber": "12346",
"openedDate": "2025-09-19T16:15:00.000Z",
"closedDate": "2025-09-19T16:30:00.000Z",
"modifiedDate": "2025-09-19T16:30:00.000Z",
"businessDate": 20250919,
"promisedDate": "2025-09-19T16:45:00.000Z",
"channelGuid": "s9t0u1v2-w3x4-f012-stu9-ef0123456789",
"source": "POS",
"duration": 900,
"dining": {
"guid": "t0u1v2w3-x4y5-0123-tuv0-f012345678ab",
"entityType": "DiningOption",
"behavior": "DINE_IN",
"curbsidePickupInfo": null
},
"restaurant": {
"guid": "d4e5f6g7-h8i9-0123-def4-56789012345a",
"entityType": "Restaurant",
"locationName": "Main Street Location",
"locationId": "MAIN_001"
},
"revenueCenter": {
"guid": "u1v2w3x4-y5z6-1234-uvw1-012345678abc",
"entityType": "RevenueCenter",
"name": "Dine In"
},
"server": {
"guid": "v2w3x4y5-z6a7-2345-vwx2-12345678abcd",
"entityType": "Employee",
"firstName": "Jane",
"lastName": "Doe",
"email": "jane.doe@restaurant.com"
},
"table": {
"guid": "w3x4y5z6-a7b8-3456-wxy3-2345678abcde",
"entityType": "Table",
"name": "Table 12"
},
"checks": [
{
"guid": "x4y5z6a7-b8c9-4567-xyz4-345678abcdef",
"entityType": "Check",
"displayNumber": "1",
"selections": [
{
"guid": "y5z6a7b8-c9d0-5678-yza5-45678abcdef0",
"entityType": "Selection",
"item": {
"guid": "z6a7b8c9-d0e1-6789-zab6-5678abcdef01",
"entityType": "MenuItem",
"name": "Grilled Chicken Sandwich",
"plu": "SAND001"
},
"itemGroup": {
"guid": "a7b8c9d0-e1f2-789a-abc7-678abcdef012",
"entityType": "MenuGroup",
"name": "Sandwiches"
},
"quantity": 1,
"unitOfMeasure": "NONE",
"selectionType": "NONE",
"deferred": false,
"preDiscountPrice": 1299,
"price": 1299,
"tax": 117,
"voided": false,
"voidDate": null,
"voidBusinessDate": null,
"modifiers": []
}
],
"customer": null,
"payments": [
{
"guid": "b8c9d0e1-f2g3-89ab-bcd8-78abcdef0123",
"entityType": "Payment",
"paidDate": "2025-09-19T16:28:00.000Z",
"paidBusinessDate": 20250919,
"type": "CASH",
"amount": 1500,
"tipAmount": 84,
"amountTendered": 1500,
"cardEntryMode": null,
"last4Digits": null,
"cardType": null
}
],
"appliedDiscounts": [],
"taxAmount": 117,
"totalAmount": 1416,
"paymentStatus": "PAID"
}
],
"appliedDiscounts": [],
"discountAmount": 0,
"netAmount": 1299,
"taxAmount": 117,
"totalAmount": 1416,
"paidDate": "2025-09-19T16:28:00.000Z",
"closed": true,
"voidDate": null,
"voidBusinessDate": null,
"voided": false,
"approvalStatus": "APPROVED",
"deliveryInfo": null
}
],
"metadata": {
"fetch_date": "2025-09-26T04:00:00.000Z",
"start_date": "2025-09-19T04:00:00.000Z",
"end_date": "2025-09-26T04:00:00.000Z",
"total_orders": 2
}
}
